通过下面几个例子，一起走进google maps 网页api开发 PS：我查了下V3的api有的说需要key,有的说不需要key，根据文档貌似是需要key的，但是我们公司的的确没用key（然后访问量起来就挂了)。。，以下的预览地址（服务端环境）会提示需要key，拷贝下来本地运行都是可以的
测试数据坐标是我随便写的，不必纠结北京香山公园怎么定位到上海了
0-初始化一个地图
// initMap就是加载后的回调函数
// 注意和echart一样mainMapLayer需要给宽度和高度地图才能显示出来
function initMap() {
console.log('common in initMap');
var myOptions = {
zoom: 11,
center: new google.maps.LatLng(31.22171, 121.352856),
mapTypeId: google.maps.MapTypeId.ROADMAP
};
var map = new google.maps.Map(document.getElementById("mainMapLayer"), myOptions);
}
//PS:谷歌地图这个地址在北京，国内可以正常使用http://ditu.google.cn/maps/api/js预览地址 ：点击访问
1-添加标记
var myCenter=new google.maps.LatLng(31.22171, 121.352856);
var myOptions = {
zoom: 11,
center: myCenter,
mapTypeId: google.maps.MapTypeId.ROADMAP
};
var map = new google.maps.Map(document.getElementById("mainMapLayer"), myOptions);
var marker=new google.maps.Marker({
position: new google.maps.LatLng(31.22171, 121.30),
map: map,
title:"Hello google Map!"
});预览地址：点击访问
1.1-添加多个标记
var myCenter = new google.maps.LatLng(31.22171, 121.352856);
var myOptions = {
zoom: 11,
center: myCenter,
// mapTypeId: google.maps.MapTypeId.ROADMAP
};
var map = new google.maps.Map(document.getElementById("mainMapLayer"), myOptions);
//地图的标记和地图中心不能太远，否则会看不到
// var marker = new google.maps.Marker({
// position: new google.maps.LatLng(31.22171, 121.30),
// map: map,
// title: "Hello google Map!"
// });
var markers=[];
var neighborhoods = [{
lat: 31.22071,
lng: 121.302800
}, {
lat: 31.22111,
lng: 121.352001
}, {
lat: 31.22371,
lng: 121.392100
}, {
lat: 31.22571,
lng: 121.372856
}, ];
for (var i = 0; i < neighborhoods.length; i++) {
addMarkerWithTimeout(neighborhoods[i], i * 500);
}
function addMarkerWithTimeout(position, timeout) {
window.setTimeout(function() {
markers.push(new google.maps.Marker({
position: position,
map: map,
animation: google.maps.Animation.DROP
}));
}, timeout);
}预览地址：点击访问
2-添加信息框
var myCenter = new google.maps.LatLng(31.22171, 121.352856);
var myOptions = {
zoom: 11,
center: myCenter,
mapTypeId: google.maps.MapTypeId.ROADMAP
};
var map = new google.maps.Map(document.getElementById("mainMapLayer"), myOptions);
var marker = new google.maps.Marker({
position: new google.maps.LatLng(31.22171, 121.30),
map: map,
title: "Hello google Map!"
});
var contentString = '<div id="content">' +
'<div id="siteNotice">' +
'</div>' +
'<div id="bodyContent">' +
'<p>我是支持HTML的提示框 </p>' +
'<input type="button" value="查看路线">' +
'</div>' +
'</div>';
var infowindow = new google.maps.InfoWindow({
content: contentString
});
marker.addListener('click', function() {
infowindow.open(map, marker);
});预览地址：点击访问
2.1-添加多个信息框
var myCenter = new google.maps.LatLng(31.22171, 121.352856);
var myOptions = {
zoom: 11,
center: myCenter,
// mapTypeId: google.maps.MapTypeId.ROADMAP
};
var map = new google.maps.Map(document.getElementById("mainMapLayer"), myOptions);
var neighborhoods = [{
lat: 31.22071,
lng: 121.302800,
title:"上海迪士尼",
content :"中国上海市黄浦区方浜中路280号。"
}, {
lat: 31.22111,
lng: 121.352001,
title:"东京迪士尼乐园",
content :"日本千叶县浦安市舞浜1-1号。"
}, {
lat: 31.22371,
lng: 121.392100,
title:"北京香山公园",
content :"北京市海淀区买卖街40号。"
}, {
lat: 31.22571,
lng: 121.372856,
title:"襄阳古隆中",
content :"湖北省襄阳市襄城区001县道隆中路6号。"
} ];
for (var i = 0; i < neighborhoods.length; i++) {
addMarkerWithTimeout(neighborhoods[i]);
}
function addMarkerWithTimeout(position) {
markers.push(new google.maps.Marker({
position: position,
map: map,
title:"hello google map"
}));
}
var contentString = '<div id="content">' +
'<div id="siteNotice">{{title}}</div>' +
'<div id="bodyContent">' +
'<p>{{content}} </p>' +
'<input type="button" value="查看路线">' +
'</div>' +
'</div>';
var infowindow = new google.maps.InfoWindow({
content: contentString
});
var j = 0;
for (j = 0; j < markers.length; j++) {
markers[j].index = j;
google.maps.event.addListener(markers[j], 'click', function() {
var that = this;
infowindow.setContent(htmlTpl(contentString,neighborhoods[that.index]));
infowindow.open(map, that);
});
}
}
function htmlTpl(tpl, data) {
return tpl.replace(/{{(\w+)}}/g, function() {
return data[arguments[1]];
});
预览地址：点击访问
3-路线导航
var directionsService = new google.maps.DirectionsService();//service用来请求导航数据
var directionsDisplay;
directionsDisplay = new google.maps.DirectionsRenderer();//渲染导航数据
directionsDisplay.setMap(map);
directionsDisplay.setPanel(document.getElementById("direction-panel"));
//出行方式选择
var aRouteWay = document.querySelectorAll('.route_way')[0];
var aAWay = aRouteWay.querySelectorAll('a');
aAWay.forEach(function(item){
item.addEventListener('click',function(){
aAWay.forEach(function(item2){
item2.className="";
})
this.className="current";
var way = this.dataset.way.toUpperCase();
calcRoute(way);
})
})
function calcRoute(way) {
var start = document.getElementById('start_point').value;
var end = document.getElementById('end_point').value;
var request = {
origin: start,
destination: end,
travelMode: google.maps.DirectionsTravelMode[way]
};
directionsService.route(request, function(response, status) {
if (status == google.maps.DirectionsStatus.OK) {
directionsDisplay.setDirections(response);
}
});
}预览地址 ：点击访问
3.1-多标记路线导航
代码太长，我就直接放地址吧 预览地址：点击访问
3.2-多标记和路线导航分离
预览地址：点击访问
